Product Description

Auto Rectangular Duct Line 2

The Auto Rectangular Duct Line 2 is engineered for high-precision fabrication of rectangular ducts, combining advanced technology with robust design to enhance efficiency and accuracy in production.


Key Features:

  • Complete Set of Equipment: Includes a metal feeding frame, leveling and grooving equipment, notching and punching equipment, cutting machinery, and an electrical control system.

  • Precision Control: Utilizes a computer-controlled closed-loop servo system, ensuring maximum working speed of 16 m/min with a length tolerance of ±0.5 mm and a diagonal tolerance of ±0.8 mm.

  • Customizable Feeding Frame: The feeding frame can be tailored to meet specific customer requirements.


Equipment Specifications:

  1. Electric Feeding Machine Frame: Features two internal-shoring material cores.

  2. Leveling Compact Bar Equipment: Ensures accurate leveling of materials.

  3. Hydraulic Pressure Attack Angle Molding: Four sets for optimal shaping.

  4. Hydraulic Shear Plate Equipment: Cuts materials with precision.

  5. Digital Controlling System: Provides user-friendly operation.

  6. Hydraulic Pressure System: Enhances cutting and shaping processes.


Additional Advantages:

  • Superior Materials: Constructed with high-quality 45# steel rollers, featuring hard chromium plating for durability.

  • Efficient Leveling: Ten-roll leveling mechanism for consistent performance.

  • Film Covering Function: Protects finished products during handling.

  • Versatile Cutting Capabilities: Can shear ordinary plates (up to 3 mm) and stainless steel (up to 1.5 mm).


Technical Parameters:

  • Thickness: 0.5 - 1.2 mm (Galvanized Steel)

  • Coiler Width Options: 1000-1250 mm or 1220-1530 mm

  • Weight Capacity: ≤6000 kg

  • Working Speed: Up to 15 m/min

  • Length Error: ±0.5 mm

  • Diagonal Error: ±0.8 mm

  • Dimensions: 7 x 1.8 x 1.6 m or 7 x 2.1 x 1.6 m

  • Weight: 4500 kg or 5000 kg

  • Motor Power: 10 kW


The Auto Rectangular Duct Line 2 enhances your production capabilities with precision, speed, and reliability. Contact us today to learn more or request a quote!
